Quiz 2.0 Welcome to your Quiz 2.0 Name: Email 1. What type of diagram is this above? a) Block Definition Diagram b) Internal Block Diagram c) Requirements Diagram d) Package Diagram None 2. w is a _______ of type __________ belonging to ________ a) part property, Environment, Weather b) part property, Weather, Unmanned Aerial System c) part property, Weather, Environment d) value property, Environment, Weather None 3. Jet Platform and Rotary Platformare ______________ of Aircraft Platform a) part properties b) instances c) reference properties d) subtypes None 4. Based on multiplicity, which configuration of Payload is valid? a) One radar, one thermal camera, one video camera b) Two radars c) Ten radars, three thermal cameras, fifteen video cameras d) All of the above None 5. Block names generally begin with ________, part property names with ______________. a) lower case letters; upper case letters b) upper case letters; lower case letters c) colons; verb phrases d) verb phrases; colons None 6. In this diagram, massActual is called a _________? a) value b) value property c) default value d) value type None 7. In this diagram, Km/hr is called a _________? a) value b) value property c) default value d) value type None 8. In the expression capacityFuel:Kg = 50, 50 is a _________? a) value b) value property c) default value d) value type None 9. Which statement is true? a) A value property must be a number. b) A value type must be a unit. c) Multiple value properties may be of the same value type d) Multiple value types may be of the same value property None 10. Which of the above could describe a UAV with four rotors? a) A b) B c) C d) All three None 11. The value properties belonging toJet Engine are __________. a) thrust b) cost, mass, KN c) cost, mass, thrust d) cost, mass, thrust, power None 12. Which of these is not a good candidate to be represented by a block? a) The UAV b) The Takeoff c) The Weather d) All three are good candidates None 13. In this diagram, Turbine could be called the _______, APU the ________. a) Subtype; supertype b) Parent; child c) Block; part property d) Block; block definition diagram. None 14. One advantage of the Multicopter UAV is ________________. a) It can represent a UAV with no rotors at all. b) It can represent a range of UAV configurations c) All the rotors must be the same. d) The rotors can all operate at the same time. None 15. The primary purpose of a BDD is to show the ___________ a) Connections between parts of the system b) Major behaviors of a system c) Structure and composition of a system d) Requirements for a system None Time's up
demo Welcome to your Quiz 1.0 Name: Email 1. Which statement is true? a) SysML has been around since the 1980’s. b) SysML was developed from UML. c) SysML was invented at Georgia Tech. d) SysML can’t be used to model software. None 2. Which of the following was not described as a benefit of MBSE? a) Better Communication b) Tighter Management Control c) Automated Requirements Verification d) Knowledge Capture and Reuse None 3. Model-based Systems Engineering means a) Creating a single model of the system b) Creating many models for the system c) Creating a SysML model of the system d) Creating many documents describing the system None 4. How many standard SysML diagram types are there? a) 2 b) 5 c) 9 d) 12 None 5. How many diagrams is a SysML model required to have? a) 0 b) 1 c) 4 d) 9 None 6. How many diagrams should a SysML model have? a) 0 b) 1 c) 9 d) As many as the modeler needs None 7. Which of the following is not a standard SysML diagram? a) Activity Diagram b) Timing Diagram c) Package Diagram d) Block Definition Diagram None 8. In this diagram header, label C designates the a) Diagram Type b) Owner Element Type c) Owner Element Name d) Diagram Name None 9. In this diagram header, label D designates the a) Diagram Type b) Owner Element Type c) Owner Element Name d) Diagram Name None 10. Identify what part of the MagicDraw window is labeled A? a) Diagram Window b) Diagram Toolbar c) Containment Browser d) Tabs Area None 11. Identify what part of the MagicDraw window is labeled B? a) Diagram Window b) Diagram Toolbar c) Containment Browser d) Tabs Area None 12. A block’s name can be edited in the _______ tab; its fill color can be edited in the ______ tab. a) Element; Symbol b) Symbol; Element c) Element; Element d) Symbol; Symbol None 13. The Specification Window is an enhanced version of the a) Symbols tabunder the Properties tab b) Containment Browser c) Element tab under the Properties tab d) Diagram toolbar None 14. Creating a new block in the SysML model is done by a) Right-clicking inside the Containment Browser and selecting Create Element → Block b) Left-clicking Block in the Diagram Toolbar and clicking inside a diagram c) Both d) Neither None 15. Which statement is not true? a) Every element in a model must appear in a diagram. b) No element can appear in a diagram if it is not in the model. c) Diagrams cannot show anything inconsistent with the model. d) A model element can appear in multiple diagrams. None Time's up
